The 22R-to-OM617 Motor Mounts position the OM617 as close to the firewall as possible, while still being able to remove the valve cover without too much extra effort. Sliding the engine back this far allows the factory radiator, hood latch, and Toyota A/C system to be retained. It is, however, recommended that you run a 3VZE radiator. These motor mounts are designed to be used with Doomsday's Transmission Crossmember Bracket and Oil Pan.


These steel motor mounts are formed and welded.


These brackets are a direct fit for 1984-1995 Toyota Pickups and 4Runners. A 1/2" spacer may be needed between these mounts and the engine block to be used on 1979-1983 Toyota Pickups and 4Runners.


These mounts are designed to work with the OEM Toyota rubber isolators. Use of solid mounts, such as Trail Gear's "bomb proof" mounts, will cause destruction of either these mounts or your frame. Something has to soak up your engine's vibrations, and the last thing you want that to be are your welds.

22R-to-OM617 Motor Mounts
